Monoclonal Anti-Eribulin Antibody

Fig.1. SDS-PAGE analysis of Eribulin_mAb014
Lane M: Precision Plus Protein™ Dual Color Standards (Bio-Rad) (Sample loaded: 5 μl)
Lane 1: Purified Eribulin_mAb014 under reducing condition (Sample loaded: 2 μg)
Lane 2: Purified Eribulin_mAb014 under non-reducing condition (Sample loaded: 2 μg)
• Recombinant protein was visualized by Coomassie Brilliant Blue R250 staining.

Fig. 2. SEC-HPLC analysis of Eribulin_mAb014
Running buffer: 2*PBS, pH 7.4
Column: Superdex 200 Increase 5/150 GL(GE, Code Number: 28-9909-45)

Fig.3. ELISA analysis of Eribulin mAb014
Coating Eribulin ADC: 1ug/ml
Add anti-Eribulin mAb: from 5ug/ml, 10-fold diluent, 8 points including 0
Add Anti-mouse IgG (Fc specific)-HRP: 1:5000

Fig.4. Sandwich ELISA analysis of Eribulin mAb014
Coating Her2 ECD protein: 2ug/ml
Add Eribulin-ADC: from 10ug/ml, 10-fold diluent, 8 points including 0
Add eribulin antibody mAb014 (mouse IgG) at 1ug/ml
Add anti-mouse IgG (Fc specific)-HRP: 1:5000
